BAT54QBZ Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: 3-XDFN Exposed Pad
- Description: DIODE SCHOTTKY 30V 200MA 3DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAT54QBZ Specifications:
- Manufacturer Product Number: BAT54QBZ
- Mfr: Nexperia USA Inc.
- Detailed Description: DIODE SCHOTTKY 30V 200MA 3DFN
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 200mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 2 µA @ 25 V
- Capacitance @ Vr, F: 10pF @ 1V, 1MHz
- Mounting Type: Surface Mount, Wettable Flank
- Package / Case: 3-XDFN Exposed Pad
- Operating Temperature - Junction: 150°C
- BAT54QBZ Nexperia(NXP), DIODE SCHOTTKY 30V 200MA 3DFN, Discrete Semiconductor Products~Diodes - Rectifiers - Single
BAT54QBZ, Nexperia authentic parts in stock from Nexperia(NXP) authorized distributors, order today, can ship immediately.
