BAV170 Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-236-3, SC-59, SOT-23-3
- Description: BAV170 - LOW-LEAKAGE DOUBLE DIOD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAV170 Specifications:
- Mfr Part: BAV170
- Mfr: Nexperia USA Inc.
- Description: BAV170 - LOW-LEAKAGE DOUBLE DIOD
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Bulk
- Series: -
- Part Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 85 V
- Current - Average Rectified (Io) (per Diode): 125mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 50 mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 5 nA @ 75 V
- Operating Temperature - Junction: -65°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- BAV170 Nexperia(NXP), BAV170 - LOW-LEAKAGE DOUBLE DIOD, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
BAV170, Nexperia authentic parts in stock from Nexperia(NXP) authorized distributors, order today, can ship immediately.
