PMBT2222AQAZ Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: 3-XDFN Exposed Pad
- Description: PMBT2222AQA/SOT1215/DFN1010D-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PMBT2222AQAZ Specifications:
- MfrPart.: PMBT2222AQAZ
- Mfr: Nexperia USA Inc.
- Description: PMBT2222AQA/SOT1215/DFN1010D-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 600 mA
- Voltage-CollectorEmitterBreakdown(Max): 40 V
- VceSaturation(Max)@IbIc: 1V @ 50mA, 500mA
- Current-CollectorCutoff(Max): 10nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 150mA, 10V
- Power-Max: 325 mW
- Frequency-Transition: 340MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 3-XDFN Exposed Pad
- PMBT2222AQAZ Nexperia(NXP), PMBT2222AQA/SOT1215/DFN1010D-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
