PMN48XPAX Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 6-TSOP
- Description: MOSFET P-CH 20V 4.1A 6TSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PMN48XPAX Specifications:
- MfrPart.: PMN48XPAX
- Mfr: Nexperia USA Inc.
- Description: MOSFET P-CH 20V 4.1A 6TSOP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 4.1A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 55mOhm @ 2.4A, 4.5V
- Vgs(th)(Max)@Id: 1.25V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 13 nC @ 4.5 V
- Vgs(Max): ±12V
- InputCapacitance(Ciss)(Max)@Vds: 1000 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 530mW (Ta), 6.25W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 6-TSOP
- PMN48XPAX Nexperia(NXP), MOSFET P-CH 20V 4.1A 6TSOP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
PMN48XPAX, Nexperia authentic parts in stock from Nexperia(NXP) authorized distributors, order today, can ship immediately.
