PMZB950UPEYL Images
- Manufacturer: Nexperia(NXP)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DFN1006B-3
- Description: MOSFET P-CH 20V 500MA DFN1006B-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PMZB950UPEYL Specifications:
- MfrPart.: PMZB950UPEYL
- Mfr: Nexperia USA Inc.
- Description: MOSFET P-CH 20V 500MA DFN1006B-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 500mA (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.2V, 4.5V
- RdsOn(Max)@IdVgs: 1.4Ohm @ 500mA, 4.5V
- Vgs(th)(Max)@Id: 950mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 2.1 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 43 pF @ 10 V
- FETFeature: -
- PowerDissipation(Max): 360mW (Ta), 2.7W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DFN1006B-3
- PMZB950UPEYL Nexperia(NXP), MOSFET P-CH 20V 500MA DFN1006B-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
